    Portable Handheld Optical Power Meter VFL With 5km / 10km Laser Source Visual Fault Locator

    Ask Lasest Price
    Brand Name : Fongko
    Model Number : FKEQU-081
    Price : Negotiatable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    • Product Details
    • Company Profile

    Portable Handheld Optical Power Meter VFL With 5km / 10km Laser Source Visual Fault Locator

    Product overview

    2 IN 1 Fiber Optic Power meter with 5km Laser source Visual Fault locator.This kind calibration type optical power meter is for handheld installation, operation and maintenance of optical fiber network special design of a precise, durable, convenient portable test instrument. With clever appearance, can choose to switch back light display, automatic shutdown function, super wide optical power test range, accurate testing accuracy and new users auto-calibration function and general interface design

    Features

    1. Support lighting
    2. Support automatic shutdown
    3. Support backlight switch
    4. Supporting Wavelength Memory Function
    6. Support user calibration
    7. Supporting simultaneous display of linear mW and non-linear index dBm
    8. Supporting SCFCST Interface
    9. Supporting external power supply such as charging treasure, computer, etc.
    10. Supporting simultaneous linear (mW) and non-linear (dBm) display
    11. Changing, work 72 hours (optional)
    12. Supporting RJ45 testing (optional)
    Wavelength range(nm)800-1700800-1700
    ConnectorFC/SC/STFC/SC/ST
    Type of connectorInGaAsInGaAs
    Power measurement range(dBm)-70~+6-50~+26
    Uncertainty±5%
    Standard wavelength (nm)850,980,1300,1310,1490,1550,1625,1650
    Display resolutionLinear display: 0.1% logarithmic display: 0.01 dBm
    650nm light source (Options)1mw/10mw/20mw/30mw/50mw
    Operating temperature (C)-10~+60
    Storage temperature (C)-30~+70
    Automatic shutdown time (min)10
    Continuous working hours of batteries (h)≥72
    Instrument size (mm)112x66x30
    Power SupplyTwo Segment 7 Batteries/
    Rechargeable Lithium Batteries (Options)
    Instrument Net Weight (g)140/150
